Conventional model

15 d/ml infusion set               0.0ml/h~1200ml/h

20 d/ml infusion set               0.0ml/h~1200ml/h

60 d/ml infusion set               0.0ml/h~300ml/h

Note:minimum resolution of setting flow rate is 0.1mL/h when rate is above 1000mL/h, the Resolution is 1mL/h.

Drip Mode

15 d/ml infusion set               0 d/min~300 d/min

20 d/ml infusion set               0 d/min~400 d/min

60 d/ml infusion set               0 d/min~300 d/min

Note:The minimum resolution dripping speed Settings 1d/min.

Accuracy

≤±2%(Note:Under the condition of the benchmark test, using high elastic silicone iv path accuracy after calibration and commissioning.)

Bubble Detector

Ultrasonic detection method:Bubble above 25ul is detected

Total Infusion Volume

0.0ml-9999ml(0.1ml/h increment,1ml/h increment if over 1000ml/h)

Volume Limit

0.0ml-9999ml(0.1ml/h increment,1ml/h increment if over 1000ml/h)

Occlusion

(H):800±200mmHg (106.7±26.7kPa)

(C):500±100mmHg (66.7±13.3kPa)

(L):300±100mmHg (40.7±13.3kPa)

History Record

These serial products can maximally store 4500 pieces of history records. The record includes the following information: Date, flow rate, alarm data, total volume delivered, occlusion pressure and syringe brand and serial number.

Alarm

Near empty alarm,Empty alarm,Door open alarm, Bubble alarm,limited value reached alarm,AC power failure,Low battery alarm,Battery empty alarm,Remind alarm,Flow regulator or inlet valve closed alarm (optional)

Power

Supply Voltage:AC100V~240V(±10%),Power Frequency: 50Hz-60Hz

Built-in Battery:DC15V Ni-MH battery(It can be replaced by lithium ion battery pack necessary.)

Working time of battery:In case the battery is fully charged, the continuous working time can

be up to 6 hours at the speed of 25ml/h.

Maximum power:30VA;Note:Before the first use of this product, the battery must be charged while being shut down for more than 12 hours.

Working Environment

Temperature:+5℃-+40℃

Relative humidity:20%-90%

Environmental pressure:860hPa-1060hPa

Transport And Storage Environment

Temperature:-20℃~+55℃;

Atmosphere Pressure:500hPa~1060hPa.

products should be stored in the relative humidity in the range of 10% ~ 93%,no corrosion gas indoor and ventilated.

Electric Safety Classification

Class I, CF type,Built-in battery,Continuous operation equipment

Water Proof Level

IPX4

Net Weight

1.8kg(include fastener)

Dimension

175mm(W)×125mm(H)×200mm(D)

Function

KVO     (keep-vein-open)

Safety lock for PURGE/BOLUS

Apply to any high elastic infusion sets

Preset occlusion detection pressure level (three levels)

Preset Volume To Be Infused

Audible and visual alarm (volume adjustable)

RS232 interface

History data memory

Standby function

Safety lock for flow rate adjust

Bubble Detector

Bolus release

Inquiry of total infused volume

Power indicator

Vehicle Power

Double CPU

Advanced Function

Adjust occlusion detection pressure

Adjust KVO rate

A single exhaust maximum limit set

Preset system time

Infusion parameters calibration

Intelligent pressure test

Preset maximum value of flow rate
